Oписание продукта

Core decoder is AK4495SEQ (not the ordinary version of the AK4495EQ, is the AK4495 version of the super series, with S tags, S chip sense than no S version of the chip, analytical and more excellent details
Today is the launch of the AK4495SEQ super version of AK4495EQ, higher accuracy, better sense of hearing, 32 bit stereo DAC high performance, can achieve a 123 DB dynamic range, 126 dB for stereo and mono output (with optional 7V analog power). It is the latest member of audio 4 Pro (TM) series. The use of a symmetric layout for the left and right channel innovative design techniques can prevent signal quality degradation, as well as a 32 bit digital operation module provides a complete 32-bit processing.
The AK4495S incorporates a newly developed circuit to achieve a rich sound field and bass represents the realization of music playback experience with less distortion. As a consideration of acoustics, the VDD, VREFH, VSS, and VREFL pins are assigned for each L and R channel. In addition, each of these L and R letter props has two tabs to avoid common impedance effects and to achieve a low impedance performance as much as possible..
VRDS-NEO VMK-3.5-20S turntable is the use of AK4495 as the core DAC
Works voltage: or AC230V version AC115V available.
Chip solutions: AK4118+AK4495SEQ + LME49720HA
Input: coaxial and Optical ,USB Need to increase the DAC card (Buy USB version, including sub card function )
Output: RCA   analog signal
Digital accept chip: AK4118
DAC decoder chip: AK4495
IV Conversion: LME49720NA49860
Size: 231X62X190mm
Distortion: <0.001%
Output level: 2V
Packing list:
DAC   x1
RCA audio cable 1pcs
